1-3GHz 50W Broadband Power Amplifier Module Class AB RF PA
1-3GHz 50W Broadband Power Amplifier Module Class AB RF PA - high-performance GaN broadband RF power amplifier with 50W (47-48 dBm) output, 1-3 GHz frequency range, Class AB design with built-in protection for test equipment and communication systems.
Overview
The UWBPA1G3G-50W is a high-performance GaN broadband power amplifier covering 1-3 GHz with 50W (47-48 dBm) continuous wave output. Class AB design ensures linearity while built-in protection circuits provide reliability for demanding RF applications.
Key Features
- GaN ultra-wideband design: 1-3 GHz full band coverage
- High output power: 50W (47-48 dBm)
- High gain: 47-50 dB
- Class AB linear amplifier
- Built-in over-temperature protection with auto shutdown
- 50 ohm input/output impedance
- Compact: 170 x 81.5 x 20 mm
- SMA-Female RF connectors
Specifications
| Parameter | Value |
|---|---|
| Model | UWBPA1G3G-50W |
| Frequency Range | 1-3 GHz |
| Output Power (CW) | 50W (47-48 dBm) |
| P1dB | 46 dBm |
| Gain | 47-50 dB |
| Input VSWR | < 1.5:1 |
| Supply Voltage | 28V (26-30V) |
| Supply Current | 0.86-9A |
| Dimensions | 170 x 81.5 x 20 mm |
| RF Connectors | SMA-Female |
| DC Interface | D-SUB-9 |
| Operating Temp | -30 to +70°C |
Applications
- Test Equipment
- Communication Systems
- Electronic Warfare
- Signal Processing
- Laboratory RF Testing
